Ashok Leyland 4225 price, gvw & detailed specifications.



Ashok Leyland 4225 10x2 MAV

 The Latest Price Range of Ashok Leyland 4225 MAV(Multi Axle Vehicle) Starts From ₹40,22,336.00 Lakhs onwards, The Price Of Ashok Leyland 4225 MAV Varies Depending on its Wheel Base, Load Body options & Specifications.

 Ashok Leyland 4225 10x2 MAV is a truck with 42,000Kg gross vehicle weight

The engine powering this truck has 2 options one is 5760 cc H series BS-6 6-cylinder,inline with iGen6 Technology producing Power of 250 HP @ 2400 rpm and a Torque of 700 Nm @ 1200-1900 rpm,

The second engine option is 6010 cc A series BS-6 4-cylinder,inline with iGen6 Technology producing Power of 250 HP @ 2200 rpm and a Torque of 900 Nm @ 1100-1800 rpm,

Ashok Leyland 4225 MAV is Available in chassis option CBC- Cab & Chassis in which load body should be built from a Type Approved Body builder

The OEM Built body options are FSD- Fixed Side Deck & HSD- High Side Deck.

The 4225 10x2 MAV comes with a wheelbase combination of 6600mm with a load body span of 28ft (8.5m) & 30ft (9.1m) .

The Detailed Specification of 4225 MAV Variant are well described below, if you are serious about buying a new truck then refer to truckexpert.in for the latest range of trucks available in India.

Ashok Leyland 4225 10x2 MAV Chassis drawings, Ashok Leyland 4225 chassis drawings, Ashok Leyland 4225 Body builder drawings, Ashok Leyland 4225 chassis layout, Ashok Leyland 4225
Ashok Leyland 4225 MAV - Chassis Drawing








Ashok leyland 4225 MAV option 1

Ashok leyland 4225 of 6600mm Wheelbase have a load body span of 28ft (8.5m), the overall dimensions of cab & chassis (chassis without load body) are mentioned above including its overall length-10960mm, overall height -2987mm / 3247mm / 3177mm, overall width-2570m, turning circle radius of 23.7m & cross-linked polymer fuel tank capacity of 220 Ltr / 300Ltr / 375 Ltr.

CHASSIS OPTIONS : CBC.

CHASSIS WITH LOAD BODY OPTION   : FSD, HSD.

Ashok leyland 4225 MAV option 2

Ashok leyland 4225 of 6600mm Wheelbase have a load body span of 30ft (9.1m), the overall dimensions of cab & chassis (chassis without load body) are mentioned above including its overall length-11560mm, overall height -2987mm/3247mm/ 3177mm, overall width-2570m, turning circle radius of 23.7m & cross-linked polymer fuel tank capacity of 220 Ltr / 300Ltr / 375 Ltr.

CHASSIS OPTIONS : CBC.

CHASSIS WITH LOAD BODY OPTION   : FSD, HSD.

Ashok leyland 4225 MAV - Engine Specification

Engine Option 1 - H6E6F25

Ashok leyland 4225 MAV comes with a H series BSVI 6-Cylinder i-Gen Technology Engine with a maximum engine output of 250 Hp @ 2400 rpm & a maximum torque of 900N-m @ 1200-1900rpm at the rear drive axle, this power is produced from a 5760cc Bs6 engine.

Engine Option 2 - A4E6F25

Ashok leyland 4225 MAV comes with a A series BSVI 4-Cylinder i-Gen Technology Engine with a maximum engine output of 250 Hp @ 2200 rpm & a maximum torque of 900N-m @ 1100-1800rpm at the rear drive axle, this power is produced from a 6010cc Bs6 engine.

Ashok leyland 4225 MAV- Transmission & Suspension

The engine of Ashok leyland 4225 is coupled with a 9 speed synchromesh Transmission system with a single plate dry plate Ceramic clutch with air assisted hydraulic booster, the clutch has a Diameter of 380mm or 395mm.

The chassis frame Section of Ashok leyland 4225 MAV is 275x75x8mm or 275x75x (8mm+6mm) Bolted Construction.

Ashok Leyland 4225 comes with Semi-elliptic Multi Leaf or Parabolic springs at Front axle & Non-Reactive Suspension or Slipper end suspension at Rear axle.

Ashok leyland 4225 MAV- Steering System

Ashok leyland 4225 have a Hydraulic assisted power steering,

Ashok leyland 4225 MAV - Cabin

The Leyland 4225 MAV truck has an option of 3 cabins “M-Cabin”, “N-Cabin”, “U-Cabin”. The “N” Type premium sleeper cabin gives a good comfort with a maximum seating capacity of 2 persons including driver.

The air conditioning is optional in Ashok leyland 4225.

Ashok leyland 4225 MAV- Brake System

The service brakes are pneumatic foot operated full air dual line systems with ABS & Auto Slack adjuster. The front & rear wheels have drum brakes.

Ashok leyland 4225 MAV- Tyre size

295 / 90 R20- 16PR & 295 / 80 R 22.5.

Ashok leyland 4225 MAV- Fuel Tank & Electrical

The fuel capacity of cross-linked polymer tank is 220Ltr & 375Ltr and Adblue capacity of 48Ltr

The Electrical system consist of 24V,120AH batteries & 150Ah for Air-conditioned vehicles.

FREQUENTLY ASKED QUESTIONS about Ashok Leyland 4225 MAV Truck.

Q. What is MAV in ashokleyland truck variants ?

A.    Multi Axle Vehicle is the abbreviation of MAV.

Q. What is the gvw ( Gross Vehicle Weight ) of ashokleyland 4225 MAV truck variant ?

A.    42,000 Kg is the gvw of ashokleyland 4225 MAV.

Q.    Available Load Body Options in Ashok Leyland 4225 MAV Truck ?

A. Ashok Leyland 4225 is available in 28ft (8.5m), 30ft (9.1m) Load body span.

Q. What all are the available wheelbase of ashokleyland 4225 MAV truck?

A.    6600mm are the available wheelbase for ashokleyland 4225 MAV .

Q What is the Tyre Size of ashokleyland 4225 MAV truck ?

A    295/90R20 – 16 PR & 295/80R22.5 is the Tyre size of ashok leyland 4225 MAV.

Q Which type of Applications does Ashokleyland 4225 truck ideal fit ?

A  Ashok Leyland 4225 is specially designed for higher payload and ideal fit for applications like Market Load, Cement, Iron & Steel, Tanker, Construction Material.

Ashok leyland 4225 10X2 Multi Axle Vehicle  is specially designed to transport cement  goods Ashok leyland 4225 10X2 Multi Axle Vehicle  is specially designed to construction materials Ashok leyland 4225 10X2 Multi Axle Vehicle  is specially designed to transport coalAshok leyland 4220 10X2 Multi Axle Vehicle  is specially designed to transport IRON & STEEL Ashok leyland 4225 10X2 Multi Axle Vehicle is specially designed to transport tanker. Ashok leyland 4225 10X2 Multi Axle Vehicle  is specially designed to transport Market Load.Ashok leyland 4220 10X2 Multi Axle Vehicle  is specially designed to transport Market Load. Ashok leyland 4225 10X2 Multi Axle Vehicle is specially designed to transport petroleum products.

Download Ashok Leyland 4225 MAV - Multi Axle Vehicle Brochure
